02.July.2020

Delivery of Fluid Transfer System

Blue Logic has successfully completed testing and delivery of the first Fluid Transfer System for installation on a well intervention vessel.

The Fluid Transfer System, FTS, is designed for offshore vessel to vessel fluid transfer. Based on Blue Logic’s Valve Stab technology and MultiDog lifting connector, the FTS ensures quick connection/disconnection with no fluid spill.

Compared to traditional vessel to vessel hose connection systems, the FTS allows operation at rougher weather conditions thus increasing operational window. Using a gimbal feature, the supply hose can swing up to 30° from the vertical axis when connected. A load monitoring system ensures controlled disconnection if the hose-tension exceed a pre-set load. Both valves, i.e. stab and receptacle valves, will be automatically closed prior to the disconnection. All pressurized parts in Super Duplex material for maximum corrosion resistance.

The system was engineered, fabricated, tested and made ready for hand-over in less than 6 months.

More information of Fluid Transfer System at our E-Sea Webshop.
